Networking Racks Wall-Mount Cabinets 12U 19" Wall-Mount Cabinet Rear Hinged Swing-Out, Glass Door 21.7" Depth Pre-Assembled

12U 19" Wall-Mount Cabinet Rear Hinged Swing-Out, Glass Door 21.7" Depth Pre-Assembled SKU: 104265

1+
$352.00
2+
$344.96
4+
$338.06
Business Member Pricing

Warranty:

  • 30-day money back guarantee
  • 15% restocking fee after 30days.
  • Safe SSL encrypted shopping

Description

Spec Sheet Assembly Guide

Pro-Series Wall Mount Cabinets organize and secure EIA-standard 19-inch rackmount equipment in network closets, offices,
classrooms, and other locaons with limited floor space. Flat-packed for easy installaon and quick deployment. Removable and
reversible front door and removable side panel design, each with quick-release mechanism, allow easy access to equipment during
installation and maintenance. The vented frames and optional cooling fans provide excellent air ventilation.


Features:

  • Fits rack equipment up to 21.7 inch deep.
  • Maximum load capacity of 132 lbs.
  • Swing away from wall on hinge for easy access to the rear of equipment.
  • Reinforced lockable door and main chassis for increased security.
  • Removable door and side panel.
  • Cable pass-through on top and bottom.
  • Rugged welded structure with ventilation at front, sides, top and bottom.

    Specs:

    Type:Enclosure
    Style:Wall-Mount
    Rack Height:12U
    Rack Depth (in. / mm): 23.6 / 600
    Maximum Device Depth (in. / mm):21.7 / 550
    Front Door Type:Tempered Glass
    Load capacity (lbs / kg):132 / 60
    Number of vertical mounting rails:4
    Number of L brackets:2
    Shelves:No
    Cable access:Top, Bottom
    Unit Dimensions (H x W x D / in.):23.5 x 23.5 x 25


    Due to the dimensions of the box, Dimensional Weight Rates will apply for this item. What is Dimensional Weight?

    ** Free freight does NOT apply to this item. **
