8Port 10/100/1000Mbps Desktop Gigabit Switch (TP-Link SG1008D) SKU: 102308
1+
$24.99
Out of Stock ETA:TBD
Business Member Pricing
Warranty: 1 Year
- 30-day money back guarantee
- 15% restocking fee after 30days.
- Safe SSL encrypted shopping
Description
TP-Link Product Page: SG1008D
The SG1008D 8-port Gigabit Ethernet Switch provides you with a high-performance, low-cost, easy-to-use, seamless and standard upgrade to improve old network to 1000Mbps network. Increase the speed of your network server and backbone connections, or make Gigabit to the desktop a reality. Power users in the home, office, work group, or creative production environment can now move large, bandwidth-intensive files faster. Transfer graphics, CGI, CAD, or multimedia files and other applications that have to move large files across the network almost instantly.
Features:
Standards and Protocols |
IEEE802.3, 802.3u, 802.3ab, 802.3x
CSMA/CD, TCP/IP |
Basic Function |
Wire-speed Performance |
MAC Address Auto-Learning and Auto-aging |
|
IEEE802.3x flow control for Full-Duplex Mode and backpressure for Half-Duplex Mode |
|
Backbound Bandwidth |
16Gbps |
MAC Address Table |
4k |
Forwarding Rate |
10BASE-T: 14880pps/port
100BASE-TX: 148800pps/port
1000BASE-T: 1488000pps/port |
Transmission Method |
Store-and-Forward |
Ports |
8 10/100/1000Mbps Auto-Negotiation RJ45 ports (Auto MDI/MDIX) |
Network Media |
EIA/TIA-568 100 ohm STP (maximum 100m)
100Base-Tx: UTP Cat.5E cable (maximum 100m)
EIA/TIA-568 100 ohm STP (maximum 100m)
1000Base-T: UTP Cat.5E cable (maximum 100m) |
LED Indicators |
Power, 10/100M, 1000M |
Safety & Emission |
FCC, CE |
Dimensions (W*D*H) |
7.9*5.5*1.1 in. (200*140*28 mm) |
Environment |
Operating Temperature: 0C~40C (32F~104F) Storage Temperature: -40C~70C (-40F~158F) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
Power |
External Power Adapter |
